5 Element Yagi for 2m.

It is a directive antenna consisting of a reflector, a dipole, I'm 5 elements, parallel to each other, each with a wavelength of about 1/5
post 21 May 2023


Antenna for UHF VHF Links

155



Antennes Antenne Jupe 432 Mhz
The sleeve antenna can be considered as a ground plane antenna whose very large number of radians has been folded along the coaxial cable to form a tube

Antenna is just a 1/4 wavelength resonator for both UHF and VHF band
This antenna is just a 1/4 wavelength resonator for both UHF and VHF band. It provides no GAIN as compared to other multi-section design

Antennes Slim Jim 432 Mhz
For a good hold of the antenna, I fixed the enamelled wire on a 12 mm pvc tube, by means of epoxy scrap, on which the enamelled wire was welded and previously etched at the points of welding.

Ariss Antenna and Satellite Antenna
A circularly polarized crossed-Yagi antenna capable of being pointed in both azimuth N-S-E-W and elevation
