Antenna for 6 meter band Halo


A square folded dipole radiates in all directions, with -4dB gain on the sides compared to the front and back side
post 18 Dec 2021


Antenna for UHF VHF Links

163



3 Stacked Yagi Antennas
The use of three antennas often represents a good compromise between increased antenna gain, mechanical feasibility, and satisfactory handleability

432Mhz Quagi,
This Quagi is optimized for 432.2Mhz operation, however it works well in a quite wide range of frequency

5 Element-Yagi fur 145 MHz
Boom Length 1705 mm, Elements diameter 8-10 mm, hollow material they are obstructed by the boom, adjustment stub range length from the central arm to the collection clamp 175-200 mm diameter of aluminum tube from 6 mm distance between stub and radiator 15 mm

10 Element for 432 MHz Winkler Antennen
The elements have direct connection to the supporting boom by a metal ring where on either side one half of the element is screwed

70cm 10-element uhf yagi
Adjust lenght of the dipole if needed important,you can also use a folded dipole with a 1:4 balun
