Understanding Common Mode and Differential Mode Currents on Transmission Lines
post 07 Nov 2020
Antenna Feed Lines Links →
To see detailed performance data for a variety of coax cable types, use the Times Microwave Systems online coax cable calculator attenuation & Power Handling Calculator
In pratica si usa un analizzatore d'antenna, tipo: AA-54 o MFJ269 o qualsivoglia altro, un T ed una terminazione uguale all'impedenza caratteristica dell'analizzatore
A Quarter wavelength of RG-58/U (VF = 0.66) at 7.040Mhz would be 23.06ft in length
Return loss is a measure of VSWR (Voltage Standing Wave Ratio), expressed in decibels db. The return-loss is caused due to impedance mismatch between two or more circuits
