Why Ladder Line?


RG-213 shop-bought at considerable expense; radiates RF when mismatched, typical loss: 4.8dB / 100m @ 30MHz. Ladder line: Easily constructed for a few cents per meter; radiates very little RF even when severely mismatched; typical loss: 0.33dB / 100m @ 30MHz
