Magnet loop for 80M - 40M
Planned Hinge-Capacitor, Remote Control via Motor-driven Excenter, Plates 25x25cm, Spacing at 80m = 625 cm2/128pF = 4.88mm,Spacing at 40m = 625cm2/14pF = 44.64mm
post 27 Apr 2024
