2m Antenna Preamplifier Vorverstaerker
With a gas-fet CF300, and switchable gain between 14 and 24 dBD, Noise figure better than 0.9dB, Continuity damping better than 0.2 dB, Transmittable power 750 W PEP to 2 meters with these prinelais, Material costs about 240 DM
post 30 Mar 2024
