Double-L Antenna For 80/160
The 80 meter and 160 meter antennas are separate, fed from a common coaxial feed line.In my case, the 80-meter and 160-meter horizontal sections are about 30 degrees apart. The 160 horizontal wires run east while the 80 wires run east-northeast.On both bands, the bulk of the current flows symmetrically in the center of the antenna, with the current peak about 45 feet off the ground at the feed point
post 10 Mar 2024
