Delta-Loop-Antenna-for-27-MHz
Delta-Loop-is-a-triangular-antenna-with-1-Lambda,-then-the-size-is-300:-27,205-=-11.03-meters,-so-for-each-side-it-is-11.03-m:-3-=-3.68-meters
Gamma-Match-Length-=-65-Cm,-3.-Gamma-Rod-Length-=-75-Cm,-4.-Jumper-length-from-Chassis-Connector-to-Gamma-Match-=-9-cm-using-3/8-inch-aluminum-tubing
post 28 Jan 2024
