Antenna W3DZZ
Standard antenna, L - 8.3 μH wound on a frame d - 50 mm. 8 winding length 80 mm. number of turns 19, C = 60 Pf. The circuit is tuned by the GIR on the frequency?, 05 MHz
post 21 May 2024
