Portable Vertical Antenna for 75m & 40m
Designing the Antenna for 3.8 MHz With a regular vertical: 62 ft. mast is required Too long Radial length 60 ft. Too long Use a telescopic mast, 27 ft.and a 3 wire umbrella on top Radial length 27 ft. Same as vertical radiator height
post 11 May 2024
